Описание
Матрица 1/3” 3 MP CMOS, разрешение 2304х1536, H.264 и MJPEG двойной поток кодирования, DWDR, день / ночь (ICR), 3DNR, AWB , AGC, BLC, Multiple мониторинг сети: Web Viewer, CMS (DSS / PSS) & DMSS, 0.1Lux / F2.0 (цвет), 0Lux / F2.0 (ИК вкл), видео-выход N/A, f=3.6мм, ИК- до 30м, IP67, Micro SD до 128GB, Поддержка Wi-Fi. RJ-45 (10 / 100Base-T), ONVIF, CGI, поддержка моб.устройств: iPhone, IPAD, Android, Windows Phone, DC12V. Металлический корпус
| Model | DH-IPC-HFW1320S-W | |
| Camera | ||
| Image Sensor | 1/3” 3Megapixel progressive scan CMOS | |
| Effective Pixels | 2304(H) ´ 1536(V) | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)s~1/100000s | |
| Min. Illumination | 0. 1Lux/F2.0(Color), 0Lux/F2.0(IR on) | |
| S/N Ratio | More than 50dB | |
| Video Output | N/A | |
| Camera Features | ||
| Max. IR LEDs Length | 30m | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Backlight Compensation | BLC / HLC / DWDR | |
| White Balance | Auto/Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D | |
| Privacy Masking | Up to 4 areas | |
| Lens | ||
| Focal Length | 3.6mm(2.8mm optional) | |
| Max Aperture | F2.0(F2.0) | |
| Focus Control | Manual | |
| Angle of View | H: 77°(100°) | |
| Lens Type | Fixed lens | |
| Mount Type | Board-in Type | |
| Video | ||
| Compression | H.264/ H.264H/H.264B/MJPEG | |
| Resolution | 3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/ VGA(640×480)/QVGA(320×240) | |
| Frame Rate | Main Stream | 3M(1 ~ 20fps)/1080P(1 ~ 25/30fps) |
| Sub Stream | VGA/QVGA(1 ~ 25/30fps) | |
| Bit Rate | H.264: 32kbps～8192kbps | |
| Corridor Mode | Support | |
| Audio | ||
| Compression | N/A | |
| Interface | N/A | |
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Wi-Fi | Wi-Fi(IEEE802.11b/g/n) 50m(open field) | |
| Protocol | IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS | |
| Compatibility | ONVIF, CGI | |
| Max. User Access | 20 users | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Auxiliary Interface | ||
| Memory Slot | Micro SD card, up to 128GB | |
| RS485 | N/A | |
| Alarm | N/A | |
| PIR Sensor Range | N/A | |
| General | ||
| Power Supply | DC12V | |
| Power Consumption | < 5.5W(IR on) | |
| Working Environment | -30°C~+50°C, Less than 95% RH | |
| Ingress Protection | IP67 | |
| Vandal Resistance | N/A | |
| Dimensions | Φ70mm×165mm | |
| Weight | 0.49Kg with package | |
