Описание
Матрица 1/3“ progressive scan CMOS. ICR Day/Night, формат записи Н.264/МJPEG, разрешение 1280x960 Pixel, 0.01LUX/ F1.2 (Color), 0.005LUX/F1.2(B/W), запись 1.3Mp/720P : 25 к/с, Bit Rate H.264: 32K ~ 8192Kbps, 1 BNC выход, micro SD до 32 Gb, АУДИОканал, BLC,HLC, DWDR, AWB, AGC, RS 485, RJ45, OSD, 4 маск.зоны, ALARM 1/1, двойное питание AC24V/DC12V/ PoE, t=-10°C...+50°C
| Model | ||
| Camera | ||
| Image Sensor | 1/3” 1.3Megapixel progressive scan CMOS | |
| Effective Pixels | 1280(H)x960(V) | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | |
| Min. Illumination | 0. 01Lux/F1.2 (Color), 0.001Lux/F1.2(B/W) | |
| S/N Ratio | More than 50dB | |
| Video Output | 1 channel BNC（1.0Vp-p，75Ω） | |
| Camera Features | ||
| Max. IR LEDs Length | N/A | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Backlight Compensation | BLC / HLC / WDR(120dB) | |
| White Balance | Auto/Sunny/Night/Outdoor/Customized | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D | |
| Privacy Masking | Up to 4 areas | |
| Ultra Defog | Support | |
| Smart focus | ABF | |
| Lens | ||
| Mount Type | C/CS | |
| Video | ||
| Compression | H.264/H.264B/H.264H/ MJPEG | |
| Resolution | 1.3M(1280×960)/720P(1280×720)/D1(704×576)/CIF(352×288) | |
| Frame Rate | Main Stream | 1.3M(1 ~ 25/30fps) |
| Sub Stream | D1/CIF(1 ~ 25/30fps) | |
| Third Stream | 720P(1-14/7fps) | |
| Bit Rate | H.264: 32K ~ 10Mbps | |
| ROI | Up to 4 areas | |
| Audio | ||
| Compression | G.711a / G.711u /AAC | |
| Interface | 1/1 channel In/Out(Built-in Mic) | |
| Smart Function(Optional) | ||
| Smart detection | Tripwire | |
| Intrusion | ||
| Abandoned/Missing | ||
| Scene Change | ||
| Audio detect | ||
| Face detect | ||
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Wi-Fi | N/A | |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,802.1x | |
| Compatibility | ONVIF ,PSIA,CGI | |
| Max. User Access | 20 users | |
Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Auxiliary Interface | ||
| Memory Slot | Micro SD, Max 128GB | |
| RS485 | 1 | |
| Alarm | 2/1 channel In/Out | |
| General | ||
| Power Supply | DC12V/AC24V, PoE (802.3af) | |
| Power Consumption | Max 10W (ABF&ICR; on) | |
| Working Environment | -30°C~+60°C, Less than 95% RH | |
| Ingress Protection | N/A | |
| Dimensions | 74.1mm×65.5mm×135.4mm | |
| Weight | 0.3Kg | |
Характеристики
| Основные атрибуты | |
|---|---|
| Производитель | Dahua Technology |
| Страна производитель | Китай |
| Тип камеры | IP |
| Форм-фактор | Корпусный |
| Применение | Внутренняя/Уличная |
| Тип матрицы | CMOS |
| Физический размер матрицы | 1/3" |
| Изображение картинки | Цветная |
| Режим съемки "День/ночь" | Да |
| Переключение режимов "День/ночь" | ICR |
| Наличие ИК-подсветки | Да |
